PR系列VCXO具有高Q值和卓越的性能,PRBST1122
來源:http://www.techzozo.com 作者:金洛鑫電子 2022年07月04
壓控晶振(VCXO)是通過紅外加控制電壓使振蕩效率可變或是可以調制的石英晶體振蕩器,其振蕩頻率由晶體決定,可用控制電壓在小范圍內進行頻率調整。VCXO 大多用于鎖相技術、頻率負反饋調制的目的。 控制電壓范圍一般為0V至2V或0V至3V。VCXO的調諧范圍為±100ppm至±200ppm。
PR系列壓控晶體振蕩器可在廣泛的工作條件和頻率范圍內實現出色的溫度穩定性。該器件由一個密封的石英晶體諧振器構成,具有高Q值,具有卓越的性能。該器件采用卷帶包裝,采用7.0x5.0mm表面貼裝陶瓷封裝,PR系列VCXO 是執行時鐘平滑、時鐘/數據恢復或頻率轉換和卡同步功能的鎖相環電路中的理想組件。PR系列VCXO具有高Q值和卓越的性能,PRBST1122,PRSONT155,VCXO晶振,ECERA小體積晶振
PR系列壓控晶體振蕩器可在廣泛的工作條件和頻率范圍內實現出色的溫度穩定性。該器件由一個密封的石英晶體諧振器構成,具有高Q值,具有卓越的性能。該器件采用卷帶包裝,采用7.0x5.0mm表面貼裝陶瓷封裝,PR系列VCXO 是執行時鐘平滑、時鐘/數據恢復或頻率轉換和卡同步功能的鎖相環電路中的理想組件。PR系列VCXO具有高Q值和卓越的性能,PRBST1122,PRSONT155,VCXO晶振,ECERA小體積晶振
